| Spindle Bore |
: |
93 mm |
| Rotation Speed |
: |
L: 0 - 37 rpm H: 0 - 75 rpm |
| Rotation Torque |
: |
L: 5.88 kN-m H:2.94kN-m |
| Feed Force |
: |
27.4 kN |
| Feed Stroke |
: |
4,200 mm |
| Feed Speed |
: |
0 - 6 m/min |
| Dimension(L*W*H) |
: |
6,500 x 1,550 x 2,550 mm |
| Gross Weight |
: |
6,000 kg ( 13,200 lbs ) |
|
APPLICATION:
Soil Mix Piling (Grout Mix Piling)
Jet Grouting,
Grout Hole Drilling, Well drilling,
Soil Investigation
FEATURES:
YBM Process Management system
Data Recording & Printing Device
Stepping device for Jet Grouting |
|
| |
|
 |
| Spindle Bore |
: |
145 mm |
| Rotation Speed |
: |
L: 0 - 45 rpm H: 0 - 90 rpm |
| Rotation Torque |
: |
L: 8.33 kN-m H: 4.17 kN-m |
| Feed Force |
: |
29.4 kN |
| Feed Stroke |
: |
6,000 mm |
| Feed Speed |
: |
0 - 4 m/min |
| Dimension(L*W*H) |
: |
7,700 x 2,000 x 2,500 mm |
| Gross Weight |
: |
8,000 kg ( 17,600 lbs ) |
|
APPLICATION:
Soil Mix Piling (Grout Mix Piling)
Jet Grouting,
Grout Hole Drilling, Well drilling,
Soil Investigation
FEATURES:
YBM Process Management system
Data Recording & Printing Device
Stepping device for Jet Grouting |
|
| |
|
|
| Spindle Bore |
: |
145 mm |
| Rotation Speed |
: |
6 - 70 rpm |
| Rotation Torque |
: |
2.6 - 19.5 kN-m |
| Feed Force |
: |
39.2 kN |
| Feed Stroke |
: |
6,000 mm |
| Feed Speed |
: |
0 - 9 m/min |
| Dimension(L*W*H) |
: |
7,920 x 2,000 x 2,500 mm |
| Gross Weight |
: |
9,400 kg ( 20,680 lbs ) |
|
APPLICATION:
Soil Mix Piling (Grout Mix Piling)
Grout Hole Drilling
Water Well Drilling,
Soil Investigation
FEATURES:
YBM Process Management system
Data Recording & Printing Device
Grout Flow Meter |
|
| |
|
 |
| Spindle Bore |
: |
175 mm |
| Rotation Speed |
: |
0 - 80 rpm |
| Rotation Torque |
: |
39.2 kN-m |
| Feed Force |
: |
83.3 kN |
| Feed Stroke |
: |
5,000 mm |
| Feed Speed |
: |
0 - 6 m/min |
| Dimension(L*W*H) |
: |
8,116 x 2,380 x 2,960 mm |
| Gross Weight |
: |
15,800 kg ( 34,760 lbs ) |
|
APPLICATION:
Soil Mix Piling (Grout Mix Piling)
Grout Hole Drilling
Water Well Drilling,
Soil Investigation
FEATURES:
YBM Process Management system
Data Recording & Printing Device
Grout Flow Meter |
|
| |
|
 |
| Spindle Bore |
: |
175 mm |
| Rotation Speed |
: |
0 - 69 rpm |
| Rotation Torque |
: |
0 - 71.2 kN-m |
| Feed Force |
: |
83.3 kN ( max ) |
| Feed Stroke |
: |
5,500 mm |
| Feed Speed |
: |
0 - 5 m/min |
| Dimension(L*W*H) |
: |
8,830 x 2,490 x 3,050 mm |
| Gross Weight |
: |
21,500 kg ( 47,461 lbs ) |
|
APPLICATION:
Soil Mix Piling (Grout Mix Piling)
Grout Hole Drilling
Water Well Drilling
FEATURES:
YBM Process Management system
Data Recording & Printing Device
Grout Flow Meter |
|
| |
|
 |
| Spindle Bore |
: |
Top Head Drive,
Dia adjustable |
| Rotation Speed |
: |
high |
: |
0 - 61 rpm |
| middle |
: |
0 - 30 rpm |
| low |
: |
0 - 15 rpm |
| Rotation Torque |
: |
high |
: |
25.1 kN |
| middle |
: |
50.1 kN |
| low |
: |
100.3 kN |
| Feed Force |
: |
198.7 kN ( max ) |
| Feed Stroke |
: |
12,500 mm |
| Feed Speed |
: |
0 - 4 ( Quick : 7m/min ) |
| Dimension(L*W*H) |
: |
12,150 x 2,800 x 3,190 mm |
| Gross Weight |
: |
37,500 kg ( 82,500 lbs ) |
|
APPLICATION:
Soil Mix Piling (Grout Mix Piling)
Grout Hole Drilling
Water Well Drilling,
Soil Investigation
FEATURES:
YBM Process Management system
Data Recording & Printing Device
Grout Flow Meter |
|
| |
|
|
