| Dimension(L*W*H) |
: |
3,150 mm x 2,000 mm x 1,850 mm |
| Weight |
: |
7,400 kg (16,300 lb) |
| PUMP |
Type |
: |
Triplex Plunger Pump |
| Stroke |
: |
150 mm |
| Plunger Dia |
: |
67 mm |
| Max, Pressure |
: |
45.0 MPa ( 6,530 psi) |
| Discharge Volume |
: |
175 - 350 L/min ( 46 - 92 gpm) |
| Invertor |
: |
30 - 60 Hz |
| Suction bore |
: |
80 mm ( 3" ) |
| Delivery bore |
: |
40 mm (1-1/2") |
| Inverter Motor |
: |
220 kW-4P |
| Voltage |
: |
AC 400V |
|
